User Interface

Unity Logo

Are we recording?

Meow Cam

Review

What is a Waypoint Graph and what problem does it solve?

  • It solves the pathfinding problem
  • Vertices repsesent safe(walkable) spots and edges represent that the space between vertices is walkable

Review

What is a NavMesh?

  • А collection of polygons that define what parts of the terrain are traversable by agents

Review

How is State Machine AI done in Unity?

  • Integrated with the animation system
  • Each state has one or more StateMachineBehaviours
  • Each StateMachineBehaviour implements some AI logic with OnStateXXX methods

User Interface Definition

  • Everything that lets the player interact with the game
  • By UI people generally mean GUI
    (Graphical User Interface)
  • The most common use cases for UI are:
    • Main Menu
    • Options Menu
    • Heads-up Display (HUD)
    • Health Bar
    • Inventory

UI Preview

UI
Source: Flat Cartoon GUI by RainbowArt

Localization and Internationalization

  • Localization (l10n) is adapting the UI for a specific language and culture (locale)
    • Some languages are written right to left
    • In some languages a word with more letters is shorter that a word with fewer letters
  • Internationalization (i18n) is designing your UI so that l10n is easy

Fonts

  • Raster fonts: every character is a 2D image
  • Vector fonts:
    • TrueType: straight lines and Bezier curves
    • Signed Distance Field (SDF): a pixel is treated not as intensity but as the distance to the nearest non-black part of the character
      • The prefered way of doing fonts in Unity
        (Text Mesh PRO)

Raster vs SDF Fonts


Source

UI in Unity

  • GameObject based
  • Has a few inbuilt UI components but allows for custom ones
  • Handles positioning, anchoring, styling
  • Can edit UI directly in the editor
  • There is also an option to draw UI with the OnGUI method

OnGUI Preview

Canvas

  • The area where UI elements reside
  • All UI elements are children of a canvas
  • Render Modes:
    • Screen Space - Overlay: renders on top of the scene
    • World Space: behaves like a normal GameObject
  • UI Scale Mode:
    • Constant Pixel Size: elements remain a constant size
    • Scale With Screen Size: the screen resizes -> the UI elements resize

Event System

  • Is automatically added to the scene along with a canvas when adding any UI element to the scene
  • Handles events like mouse and touch
  • Can tap into it by implementing these interfaces:
    • IPointerEnterHandler
    • IPointerExitHandler
    • IPointerClickHandler

RectTransform

  • Every UI element has a RectTransform instead of a regular Transform. It has a:
    • Pivot: point relative to which the element is rotated
    • Anchor: points relative to which the element is positioned

UI Components

  • Text
  • Image
  • Button
  • Toggle
  • Slider
  • Input Field
  • Panel

Text Mesh Pro

  • An implementation of SDF for Unity fonts
  • To make a font into a TMP font go to:
    Window/TextMeshPro/Font Asset Creator

Layout Group Components

They help organize groups of UI elements

  • Horizontal Layout Group
  • Vertical Layout Group
  • Layout Element

UnityEvent

  • Same as a regular event but visible in the Editor
  • Used in UI callbacks like OnClick
    • A designer can assign OnClick behaviour without writing code

UI in Code

using UnityEngine.SceneManagement;
using UnityEngine.EventSystems;
using UnityEngine.Events;
using UnityEngine.UI;
using TMPro;

public class MenuItem : MonoBehaviour,
                        IPointerEnterHandler,
                        IPointerExitHandler,
                        IPointerClickHandler {

    public Text regularUIText;
    public TextMeshProUGUI tmpText;
    public UnityEvent OnClick;

    public void OnPointerEnter(PointerEventData eventData) {
        tmpText.text = "...";
        //...
    }

    public void OnPointerExit(PointerEventData eventData) {
        //...
    }

    public void OnPointerClick(PointerEventData eventData) {
        OnClick?.Invoke();
        SceneManager.LoadScene("StartSceneName");
    }
}

Unity GUI Live Demo

Extra Resources

Questions?
